DS-2016 3-way line array speaker

  • 900W RMS(AES) power handling
  • 132dB continuous SPL output
  • Three-point integrated hoisting system.
  • Matt black polyurea paint

DS-2016 is a high-performance speaker with a small body and large energy with six built-in drivers. The whole box is only 70cm in width and 31cm in height. In the middle of the box is the mid-range horn, driven by two 8-inch cone speakers.

The treble driver includes two 3-inch compression drivers to promote the new development of a 10-degree vertical coverage wave generator, which is installed on the same axis as the mid-frequency driver. In the horizontal coverage angle, you can choose 80 degrees and 120 degrees. The mid-low frequency playback is handled by two 10-inch long-stroke woofers.

It is worth mentioning that the 4 cone speakers below 400Hz generate power at the same time to ensure solid mid-low frequency and strong impact. This means that DS-2016 can even compete with larger dual 12-inch systems. At the same time, it should be equipped with a simple and safe handling device and a quick setup and disassembly system.

The DS-2016’s 3-point integrated hoisting system, and its innovative logarithmic angle adjustment mechanism, ensure that the linear array has accurate bending and projection angles, even for the backcourt of large venues. The same accuracy can be achieved. Whether you start crawlers hanging from the ground, or lift them one by one from cabinets, mobile trucks, or stack installation on the ground, all kinds of installation methods can be realized. Very simple, safe, and fast.

Physical Data

Connectors2 x Nl4
 Connection MethodL; +1, -1,MF(HF); +2, -2
MaterialHigh density multilayer plywood
FinishMatt black polyurea paint
GrillePorous steel mesh
Cabinet Size(W×H×D)700x310x595mm
Shipping Carton Size (W xH x D)800x400x686mm
 Weight39.8kg net/43kg gross

Technical Specification

Type 3-way line array speaker
Power Handling (AES)900W RMS
 Nominal ImpedanceLF;8Ω, MF/HF;8Ω
Average Sensitivity(1w/1m)MF/HF;108dB, LF;98dB
Maximum SPL/1m132dB continuous
 Frequency Response90Hz-19KHz(±3dB)
 Nominal Directivity(-6dB)80°(H) x10°(V) (adjustable)
 Recommended AmplifierLF;800W8Ω, MF/HF;600W 8Ω
 LF Driver2×10″neodymium driver
MF Driver2x 8″neodymium driver
HF Driver2x (75mm) neodymium compression driver
